Body Material

Aluminum

Dimension

600x600mm

Weight

2 kg approx

In progress Protection

 Ip-20

Cover

Acrylic

 Gasket

Silicon

Accessories

Stainless Steel

Paint

Powder Coating

Mounting

C Clamp

Power Cord

1mm triple shield wire

Cerficate

CE, RoHS, BIS, FCC,BEE

Voltage Range

90V-270V AC

Power Consumption

 As per sheet below

PF

 >0.95

THD

<10%

Phase type

Single phase

Internal wiring

Teflon

Input wire

3 Core (Red Phase, Black Neutral, Green Ground)

Frequency

50Hz-60Hz

Efficiency

>85%

 Illuminance Design

LED + Reflector

Storage Temperature

 -25C ~ +65C(Best 25C)

Available wattages

30, 40, 50, 60

No. of LEDs

30, 40, 50, 60

Lumens Output (Datasheet)

145 lumens/Watts

Color Temperature

2700~7000k(Optional)

Beam Angle

120

CRI

>80 Ra

Operating Temp.

-40C to 60C

Life Span

>50000H
