Body Material

Aluminum

Dimension

1000x330x120mm

Weight

12 Kg

Ingress Protection

IP-65

Cover

Toughened Glass

Gasket

Silicon

Accessories

Stainless Steel

Paint

Powder Coating

Mounting

C Clamp

Power

Cord 1 mm2 triple shield wire

Certificate

CE, RoHS, BIS, FCC, BEE

Voltage Range

90V-290V AC

Power Consumption

As per sheet below

PF

>0.95

THD

<10%

Phase type

Single phase

Internal wiring

Teflon

Input wire

3 Core (Red Phase, Black Neutral, Green Ground)

Frequency

50Hz-60Hz

Efficiency

>85%

Illuminance Design

LED + Reflector

Storage Temperature

-25C ~ +65C(Best 25C)

Available wattages

400,450W

No. of LEDs

400 ,480

Lumens Output (Data sheet)

145 lumens/Watts

Color Temperature

2800~6500k(optional)

Beam Angle

120

CRI

>80 Ra

Operating Temp.

-40C to 60C

Life Span

>50000H
