High Bay Light

Product Details:

Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Product Description

Unique Features: Designed and die casted with high class LM-06 grade aluminium supported with all SS 304 grade accessories, toughened glass and equipped with LM 80 cer ed LEDs and electronic component to perform and give best possible results.

Housing Specifications

Body Material	Aluminum
Dimension	510x260mm
Weight	8Kg
Ingress Protection	IP-65
Cover	Toughened Glass
Gasket	Silicon
Accessories	Stainless Steel
Paint	Powder Coating
Mounting	C Clamp
Power Cord	1mm²triple shield wire
Certicate	CE, RoHS, BIS, FCC, BEE

Technical Specifications

Voltage Range	90V-270V AC
Power Consumption	As per sheet below
PF	>0.95
THD	<10%
Phase type	Single phase
Internal wiring	Teon
Input wire	3 Core (Red Phase, Black Neutral, Green Ground)
Frequency	50Hz-60Hz
Eciency	>85%
illuminance Design	LED + Reector
Storage Temperature	-25C ~ +65C(Best 25C)
