Body Material

Aluminum Die Casng

Dimension

268mm Dia,320mm ht.

Weight

7 Kg

In progress Protection

 Ip-65

Commanding Height

1-20 ft.

Accessories

Stainless Steel

Paint

Powder Coating

Mounting

C Clamp/I bolt

Power Cord

0.75mm2 triple shield wire

Cerficate

CE, RoHS, BIS, FCC,BEE

Voltage Range

90V-290V AC

Power Consumption

 As per sheet below

PF

 >0.95

THD

<10%

Phase type

Single phase

Internal wiring

Teflon

Input wire

3 Core (Red Phase, Black Neutral, Green Ground)

Frequency

50Hz-60Hz

Efficiency

>85%

 Illuminance Design

LED + Reflector

Storage Temperature

 -25°C ~ +65°C(Best 25°C)

Available wattages

50-150 W

No. of LEDs

50-150

Lumens Output (Datasheet)

145 lumens/Watts

Color Temperature

5500~6500k

Beam Angle

120°

CRI

>80 Ra

Operating Temp.

-40°C to 60°C

Life Span

>50000H
